8.2 Drive Options and Peripheral Devices
8.2 Drive Options and Peripheral Devices
Table 8.1 lists the names of the various accessories and options available for YASKAWA drives. Contact YASKAWA or
your YASKAWA agent to order these peripheral devices.
• Pe
ripheral Device Selection: Refer to the YASKAWA catalog for selection and part numbers.
• Per
ipheral Device Installation: Refer to the corresponding option manual for installation instructions.
Table 8.1 Available Peripheral Devices
Option Model Number Description
Power Options
DC Reactor
–
Improves the power factor by suppressing harmonic distortion from the power
supply.
AC Reactor
–
Protects the drive when operating from a large power supply and improves the
power factor by suppressing harmonic distortion. Highly recommended for power
supplies that exceed 600 kVA.
Braking Resistor
ERF-150WJ Series
For use with systems that require dynamic braking with up to 3% ED. If higher
ED is required, use a Braking Resistor Unit.
Braking Unit
CDBR Series External braking transistor
Input / Output Option Cards
Analog Input
AI-A3
Allows high precision, high resolution analog reference input.
Input channels: 3
Voltage input: -10 to 10 Vdc (20 k), 13 bit signed
Current input: 4 to 20 mA or 0 to 20 mA (250 ), 12 bit
Analog Monitor
AO-A3
Provides extra multi-function analog output terminals.
Output channels: 2
Output voltage: -10 to 10 V, 11 bit (signed)
Condenser Cover ECAT31726-1, ECAT31698-1
This cover protects the DC bus capacitors when mounting the heatsink outside the
enclosure. It is required for UL approval.
For more information, contact our sales department directly or your nearest
YASKAWA representative.
Digital Input
DI-A3
Used to set the frequency reference by digital inputs
Input channels: 18 (including SET signal and SIGN signal)
Input signal type: BCD 16 bit (4 digit), 12 bit (3 digit), 8 bit (2 digit)
Input signal: 24 Vdc, 8 mA
Digital Output
DO-A3
Provides extra insulated multi-function digital outputs.
Photocoupler relays: 6 (48 V, up to 50 mA)
Contact relays: 2 (250 Vac/up to 1 A, 30 Vdc/up to 1 A)
Motor Speed Feedback Option Cards
Motor PG Feedback Open Collector
Interface
PG-B3
For speed feedback input by connecting a motor encoder
Input: 3 track (can be used with one or two tracks), for HTL encoder connection,
50 kHz max
Output: 3 track, open collector
Encoder power supply: 12 V, max current 200 mA
Motor PG Feedback Line Driver
Interface
PG-X3
For speed feedback input by connecting a motor encoder
Input: 3 track (can be used with one or two tracks), line driver, 300 kHz max
Output: 3 track, line driver
Encoder power supply: 5 V or 12 V, max current 200 mA
EnDat Encoder
PG-F3
For speed feedback input by connecting a motor encoder.
Encoder type: EnDat 2.1/01, EnDat 2.2/01, and EnDat 2.2/22 (HEIDENHAIN),
HIPERFACE (SICK STEGMANN)
Maximum input frequency: 50 kHz
Pulse monitor: Matches RS-422 level
Output voltage: 5 V5%, 8 V10%
Maximum output current: 200 mA
Wiring length: 20 m max. for the encoder, 30 m max. for the pulse monitor
Note: 1. This option card can only be used in CLV/PM.
2. Not available with models CIMR-A4A0930 and 4A1200.
Motor Feedback Resolver Interface PG-RT3
For motor speed feedback by connecting a resolver (TS2640N321E64 by
Tamagawa Seiki Co., LTD).
Input voltage: 7 Vac rms 10 kHz
Transformation ratio: 0.5 ± 5%
maximum input current: 100 mA rms
Note: Not available with models CIMR-A4A0930 and 4A1200.
Communication Options Cards
PROFIBUS-DP SI-P3 Connects to a PROFIBUS-DP network.
CC-Link SI-C3 Connects to a CC-Link network
DeviceNet SI-N3 Connects to a DeviceNet network
CANopen SI-S3 Connects to a CANopen network
MECHATROLINK-II SI-T3 Connects to a MECHATROLINK-II network
MECHATROLINK-III SI-ET3 Connects to a MECHATROLINK-III network.
EtherNet/IP SI-EN3 Connects to an EtherNet/IP network
Modbus TCP/IP SI-EM3 Connects to a Modbus TCP/IP network
LONWORKS SI-W3 Connects to a LONWORKS network
Interface Options
LED Operator
JVOP-182
5-digits LED operator; max. cable length for remote usage: 3 m
Remote Control Extension Cable WV001/WV003
Extension cable (1 m or 3 m) to connect the digital operator for remote operation
RJ-45, 8 pin straight through, UTP CAT5e cable
