A.2 Three-Phase 200 V Class Drives
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 439
Specifications
A
A.2 Three-Phase 200 V Class Drives
Table A.2 Power Ratings (Three-Phase 200 V Class)
Item
<1> The motor capacity (kW) refers to a YASKAWA 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
connections, and power supply impedance.
<3> DC is not available for UL standards.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<6> Carrier frequency can be increased up the 8 kHz while keeping this current rating. Higher carrier frequency settings require derating.
<7> Carrier frequency can be increased up the 5 kHz while keeping this current rating. Higher carrier frequency settings require derating.
Specification
CIMR-A2A 0004 0006 0010 0012 0021 0030 0040 0056 0069 0081 0110 0138 0169 0211 0250 0312 0360 0415
Maximum Applicable Motor
Capacity (kW)
<1>
HD Rating 0.55 0.75 1.5 2.2 4.0 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
ND Rating 0.75 1.5 2.2 3 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 110
Input
Input Current (A) <2>
HD Rating 2.9 5.8 7.5 11 18.9 28 37 52 68 80 82 111 136 164 200 271 324 394
ND Rating 3.9 7.3 10.8 13.9 24 37 52 68 80 92 111 136 164 200 271 324 394 394
Rated Voltage
Rated Frequency
Three-phase 200 to 240 Vac 50/60 Hz/270 to 340 Vdc
<3>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
HD Rating 1.3 2.7 3.4 5.0 8.6 13 17 24 31 37 37 51 62 75 91 124 148 180
ND Rating 1.8 3.3 4.9 6.4 11 17 24 31 37 42 51 62 75 91 124 148 180 215
Output
Rated Output Capacity
(kVA)
<4>
HD Rating 1.2 1.9 3 4.2 6.7 9.5 12.6 17.9 23 29 32 44 55 69 82 108 132 158
ND Rating 1.3 2.3 4.9 6.4 8.5 11 17 24 31 37 42 53 64 80 95 119 137 158
Rated Output Current
(A)
HD Rating
3.2
<6>
5
<6>
8
<6>
11
<6>
17.5
<6>
25
<6>
33
<6>
47
<6>
60
<6>
75
<6>
85
<6>
115
<6>
145
<7>
180
<7>
215
<7>
283
<7>
346
<7>
415
<5>
ND
Rating
<5>
3.5 6 9.6 12 21 30 40 56 69 81 110 138 169 211 250 312 360 415
Overload Tolerance
HD Rating: 150% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
ND Rating: 120% of rated output current for 60 s
Carrier Frequency
User adjustable between 2 and 15 kHz
User adjustable between 2 and 10 kHz
Maximum Output Voltage (V)
Three-phase 200 to 240 Vac (proportional to input voltage)
Maximum Output Frequency (Hz)
400 Hz (user-set)

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
