1.4 Drive Models and Enclosure Types
1.4 Drive Models and Enclosure Types
Two types of enclosures are offered for A1000 drives.
• IP00 enclosure models are designed for installa
tion in an enclosure panel that serves to protect personnel from injury
caused by accidentally touching live parts.
• IP20/NEMA 1, UL Type 1 enclosure models mount to an indoor wall or in an enclosure panel.
Table 1.5 describes drive enclosures and models.
Table 1.5 Drive Models and Enclosure Types
Voltage Class
<1> Removing the top protective cover from an IP20/NEMA 1, UL Type 1 enclosure drive voids NEMA 1, UL Type 1 protection but still keeps
IP20 conformity.
Enclosure Type
IP20/NEMA 1, UL Type 1 Enclosure
CIMR-A
<1>
IP00 Enclosure
CIMR-A
Three-Phase
200 V Class
2A0004F –
2A0006F –
2A0010F –
2A0012F –
2A0021F –
2A0030F –
2A0040F –
2A0056F –
2A0069F –
2A0081F –
– 2A0110A
– 2A0138A
– 2A0169A
– 2A0211A
– 2A0250A
– 2A0312A
– 2A0360A
–
2A0415A
Three-Phase
400 V Class
4A0002F –
4A0004F –
4A0005F –
4A0007F –
4A0009F –
4A0011F –
4A0018F –
4A0023F –
4A0031F –
4A0038F –
4A0044F –
– 4A0058A
– 4A0072A
– 4A0088A
– 4A0103A
– 4A0139A
– 4A0165A
– 4A0208A
– 4A0250A
– 4A0296A
– 4A0362A
– 4A0414A
– 4A0515A
– 4A0675A
– 4A0930A
– 4A1200A

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
