YASKAWA A1000 Technical Manual

A.5 Drive Watt Loss Data
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 443
Specifications
A
A.5 Drive Watt Loss Data
Table A.4 Watt Loss 200 V Class Three-Phase Models
Table A.5 Watt Loss 400 V Class Three-Phase Models
Model Number
CIMR-A
<1> These values assume the carrier frequency is set to 8 kHz or less.
<2> These values assume the carrier frequency is set to 5 kHz or less.
<3> These values assume the carrier frequency is set to 2 kHz.
Heavy Duty Normal Duty
Rated Amps (A)
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
Rated Amps (A)
<3>
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
2A0004 3.2 <1> 14.8 44 59 3.5 18.4 47 66
2A0006 5.0 <1> 24 48 72 6.0 31 51 82
2A0010 8.0 <1> 43 52 95 9.6 57 58 115
2A0012 11.0 <1> 64 58 122 12.0 77 64 141
2A0021 17.5 <1> 101 67 168 21 138 83 222
2A0030 25 <1> 194 92 287 30 262 117 379
2A0040 33 <1> 214 105 319 40 293 145 437
2A0056 47 <1> 280 130 410 56 371 175 546
2A0069 60 <1> 395 163 558 69 491 205 696
2A0081 75 <1> 460 221 681 81 527 257 785
2A0110 85 <1> 510 211 721 110 719 286 1005
2A0138 115 <1> 662 250 912 138 842 312 1154
2A0169 145 <1> 816 306 1122 169 1014 380 1394
2A0211 180 <2> 976 378 1354 211 1218 473 1691
2A0250 215 <2> 1514 466 1980 250 1764 594 2358
2A0312 283 <2> 1936 588 2524 312 2020 665 2686
2A0360 346 <2> 2564 783 3347 360 2698 894 3591
2A0415 415 <3> 2672 954 3626 415 2672 954 3626
Model Number
CIMR-A
<1> These values assume the carrier frequency is set to 8 kHz or less.
<2> These values assume the carrier frequency is set to 5 kHz or less.
<3> These values assume the carrier frequency is set to 2 kHz.
Heavy Duty Normal Duty
Rated Amps (A)
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
Rated Amps (A)
<3>
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
4A0002 1.8 <1> 15.9 45 61 2.1 20 48 68
4A0004 3.4 <1> 25 46 70 4.1 32 49 81
4A0005 4.8 <1> 37 49 87 5.4 45 53 97
4A0007 5.5 <1> 48 53 101 6.9 62 59 121
4A0009 7.2 <1> 53 55 108 8.8 66 60 126
4A0011 9.2 <1> 69 61 130 11.1 89 73 162
4A0018 14.8 <1> 135 86 221 17.5 177 108 285
4A0023 18.0 <1> 150 97 247 23 216 138 354
4A0031 24 <1> 208 115 323 31 295 161 455
4A0038 31 <1> 263 141 403 38 340 182 521
4A0044 39 <1> 330 179 509 44 390 209 599
4A0058 45 <1> 349 170 518 58 471 215 686
4A0072 60 <1> 484 217 701 72 605 265 870
4A0088 75 <1> 563 254 817 88 684 308 993
4A0103 91 <1> 723 299 1022 103 848 357 1205
4A0139 112 <2> 908 416 1325 139 1215 534 1749
4A0165 150 <2> 1340 580 1920 165 1557 668 2224
4A0208 180 <2> 1771 541 2313 208 1800 607 2408
4A0250 216 <2> 2360 715 3075 250 2379 803 3182
4A0296 260 <2> 2391 787 3178 296 2448 905 3353
4A0362 304 <2> 3075 985 4060 362 3168 1130 4298
4A0414 370 <2> 3578 1164 4742 414 3443 1295 4738
4A0515 450 <3> 3972 1386 5358 515 4850 1668 6518
4A0675 605 <3> 4191 1685 5875 675 4861 2037 6898
4A0930 810 <3> 6912 2455 9367 930 8476 2952 11428
4A1200 1090 <3> 7626 3155 10781 1200 8572 3612 12184

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
