6.3 Drive Alarms, Faults, and Errors
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 331
Alarm and Error Displays
Faults
Table 6.9 gives an overview of possible fault codes. As conditions such as overvoltage can trip both a fault and an alarm,
it is important to distinguish betwe
en faults and alarms in order to find the right corrective action.
When the drive detects a fault, the ALM indicator LEDs lights and the fault code appears on
the display. The drive fault
contact MA-MB-MC will be triggered. If the ALM LED blinks and the code appearing on the operator screen is flashes,
then an alarm has been detected. See Minor Faults and Alarms on page 333 for a list of alarm codes.
Table 6.9 Fault Displays (1)
Digital Operator Display
Name Page
Digital Operator Display
Name Page
LED Operator LCD Operator LED Operator LCD Operator
boL Braking Transistor Overload Fault 336 dv2 Z Pulse Noise Fault Detection 339
bUS Option Communication Error 336 dv3 Inversion Detection 339
CE
MEMOBUS/Modbus Communication
Error
336 dv4 Inversion Prevention Detection 339
CF Control Fault 336 dv7 Polarity Judge Timeout 339
CoF Current Offset Fault 336
, dWAL,
dWFL
DriveWorksEZ Fault 339
,
<1>
CPF00, CPF01 Control Circuit Error 337
dWF1
EEPROM Memory DriveWorksEZ Data
Err
or
339
CPF02 A/D Conversion Error 337 E5 MECHATROLINK Watchdog Timer Error 340
CPF03 Control Board Connection Error 337 EF0 Option Card External Fault 340
<4>
CPF06 EEPROM Memory Data Error 337
to
EF1 to EF8 External Fault (input terminal S1 to S8) 340
,
CPF07,
CPF08
Terminal Board Connection Error 337
Err EEPROM Write Error 340
CPF11 RAM Fault 337 FAn Internal Fan Fault 340
CPF12 FLASH Memory Fault 337 FbH Excessive PID Feedback 340
CPF13 Watchdog Circuit Exception 337 FbL PID Feedback Loss 341
CPF14 Control Circuit Fault 337 GF Ground Fault 341
CPF16 Clock Fault 337 LF Output Phase Loss 341
CPF17 Timing Fault 338 LF2 Output Current Imbalance 341
CPF18 Control Circuit Fault 338
<2>
LF3 Power Unit Output Phase Loss 3 341
CPF19 Control Circuit Fault 338 LSo LSo Fault 342
,
<1>
CPF20, CPF21 Control Circuit Error 338
nSE Node Setup Error 342
oC Overcurrent 342
CPF22 Hybrid IC Error
338
<4>
oFA00
Option Card Connection Error at Option
Po
rt CN5-A
342
CPF23 Control Board Connection Error 338 oFA01 Option Card Fault at Option Port CN5-A 343
<4>
CPF24 Drive Unit Signal Fault 338
to
oFA03 to oFA06
Option Card Error Occurred at Option Port
CN5-A
343
CPF25 Terminal Board not Connected 338
to
,
to
<2>
CPF26 to CPF35,
CPF40 to CPF45
Control Circuit Error 338
,
oFA10, oFA11
Option Card Error Occurred at Option Port
CN
5-A
343
to
oFA12 to oFA17 Option Card Connection Error (CN5-A) 343
dEv
Speed Deviation (for Control Mode with
PG and PM
Open Loop Vector Control
Mode without PG)
338
to
oFA30 to oFA43
Comm. Option Card Connection Error
(C
N5-A)
343
dv1 Z Pulse Fault 339
<4>
oFb00 Option Card Fault at Option Port CN5-B 343
To Next Page
