B.3 Parameter Table
466 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
d: References
Reference parameters are used to set the various frequency reference values during operation.
d1: Frequency Reference
No.(Addr.) Name Description Setting Page
d1-01
(280H)
<20> Range upper limit is determined by the maximum output frequency (E1-04) and the upper limit of the frequency reference (d2-01).
<63> The value of o1-03 is changed to 1 and the unit is also changed to a percentage (%) when the control mode is set to CLV/PM or AOLV/PM.
Frequency Reference 1
Sets the frequency reference for the drive. Setting units are determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the unit is changed to percentage automatically
when A1-02 is set to 6 or 7
Default: 0.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<20> <63>
198
d1-02
(281H)
Frequency Reference 2 198
d1-03
(282H)
Frequency Reference 3 198
d1-04
(283H)
Frequency Reference 4 198
d1-05
(284H)
Frequency Reference 5 198
d1-06
(285H)
Frequency Reference 6 198
d1-07
(286H)
Frequency Reference 7 198
d1-08
(287H)
Frequency Reference 8 198
d1-09
(288H)
Frequency Reference 9 198
d1-10
(28BH)
Frequency Reference 10 198
d1-11
(28CH)
Frequency Reference 11 198
d1-12
(28DH)
Frequency Reference 12 198
d1-13
(28EH)
Frequency Reference 13 198
d1-14
(28FH)
Frequency Reference 14 198
d1-15
(290H)
Frequency Reference 15 198
d1-16
(291H)
Frequency Reference 16 198
d1-17
(292H)
Jog Frequency Reference
Sets the jog frequency reference. Setting units are determined by parameter o1-03.
Default: 6.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<20> <63>
198
