YASKAWA A1000

1.5 Component Names
36 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
 IP00 Enclosure
 Three-Phase AC200 V CIMR-A2A0110A, 0138A
Three-Phase AC400 V CIMR-A4A0058A to 0103A
Figure 1.3
Figure 1.3 Exploded View of IP00 Enclosure Components (CIMR-A2A0110A)
A – Terminal board H – Optional 24 V DC power
supply connector cover
B – Front cover
C – USB port (type-B) I – Heatsink
D – Digital operator J – Mounting hole
E – Drive Cover K – Cooling fan
F – Front cover screw L – Fan cover
G – Terminal cover
L
K
J
I
H
A
B
C
F
D
E
G
