A.6 Drive Derating Data
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 445
Table A.7 Carrier Frequency and Current Derating (AOLV/PM Control Mode)
Three-Phase 200 V Class Three-Phase 400 V Class
Model
CIMR-A
Rated Current (A)
Model
CIMR-A
Rated Current (A)
Heavy Duty Rating (HD) Normal Duty Rating (ND) Heavy Duty Rating (HD) Normal Duty Rating (ND)
2 kHz 4 kHz 12 kHz 2 kHz 4 kHz 12 kHz 2 kHz 4 kHz 12 kHz 2 kHz 4 kHz 12 kHz
2A0004 3.2 3.2 2.3 3.5 3.5 2.3 4A0002 1.8 1.8 0.8 2.1 2 0.8
2A0006 5 5 3.6 6 5.6 3.5 4A0004 3.4 3.4 1.5 4.1 3.8 1.5
2A0010 8 8 5.7 9.6 8.8 5.6 4A0005 4.8 4.8 2.1 5.4 5.3 2.1
2A0012 11 11 7.9 12 11.6 7.9 4A0007 5.5 5.5 2.4 6.9 6.1 2.4
2A0021 17.5 17.5 12.5 21 19.6 12.1 4A0009 7.2 7.2 3.1 8.8 8 3.1
2A0030 25 25 17.9 30 27.5 17.5 4A0011 9.2 9.2 3.9 11.1 10.3 3.9
2A0040 33 33 23.6 40 36.7 23.4 4A0018 14.8 14.8 6.3 17.5 16.5 6.3
2A0056 47 47 33.6 56 51 33 4A0023 18 18 7.7 23 20.1 7.7
2A0069 60 60 43 69 64 43 4A0031 24 24 10.3 30.9 26.7 10.3
2A0081 75 75 43 81 80 43 4A0038
31 31 13.3 38 34.5 13.3
2A0110 85 85 49 110 99 55 4A0044 39 39 16.7 44 41.6 17.3
2A0138 115 115 66 138 124 66 4A0058 45 45 19 58 50 19
4A0072 60 60 26 72 67 26
4A0088 75 75 32 88 83 32
4A0103 91 91 39 103 100 39
Three-Phase 200 V Class Three-Phase 400 V Class
Model
CIMR-A
Rated Current (A)
Model
CIMR-A
Rated Current (A)
Heavy Duty Rating (HD) Normal Duty Rating (ND) Heavy Duty Rating (HD) Normal Duty Rating (ND)
2 kHz 4 kHz 10 kHz 2 kHz 4 kHz 10 kHz 2 kHz 4 kHz 10 kHz 2 kHz 4 kHz 10 kHz
2A0169 145 139 87 169 146 78 4A0139 112 105 45 139 113 35
2A0211 180 173 108 211 182 96 4A0165 150 141 60 165 139 62
2A0250 215 206 129 250 217 116 4A0208 180 169 72 208 173 67
2A0312 283 272 170 312 275 165 4A0250 216 203 86 250 208 81
2A0360 346 332 208 360 324 217 4A0296 260 244 104 296 247 101
2A0415 415 398 249 415 379 273 4A0362 304 286 122 362 298 106
4A0414 370 348 148 414 348 148
4A0515 450 338 – 515 338 –
4A0675 605 454 – 675 454 –
4A0930 810 608 – 930 609 –
4A1200 1090 818 – 1200 807 –
