YOKOGAWA DLM4000 Series User Manual

xi
IM DLM4038-02EN
Place alert marks in front of section 1.1 and 16.1
Contents
Chapter 12 Analyzing and Searching Serial Bus Signals
12.1 Analyzing and Searching FlexRay Bus Signals (Option) ............................................... 12-1
12.2 Analyzing and Searching CAN Bus Signals (Option) ..................................................... 12-5
12.3 Analyzing and Searching CAN FD Bus Signals (Option) ............................................... 12-9
12.4 Analyzing and Searching LIN Bus Signals (Option) ..................................................... 12-13
12.5 Analyzing and Searching CXPI Bus Signals (Option) .................................................. 12-17
12.6 Analyzing and Searching SENT Signals (Option) ........................................................ 12-24
12.7 Analyzing and Searching PSI5 Airbag Signals (Option) ............................................... 12-31
12.8 Analyzing and Searching UART Signals (Option) ........................................................ 12-39
12.9 Analyzing and Searching I
2
C Bus Signals (Option) ...................................................... 12-45
12.10 Analyzing and Searching SPI Bus Signals (Option) ..................................................... 12-51
12.11 Analyzing and Searching User-Defined Serial Bus Signals ......................................... 12-57
12.12 Displaying Multiple Lists ............................................................................................... 12-61
Chapter 13 Waveform Histogram Display
13.1 Displaying Waveform Histograms .................................................................................. 13-1
13.2 Measuring Histogram Parameters .................................................................................. 13-2
Chapter 14 Power Supply Analysis (Power Analysis & Power Measurement;
Option)
14.1 Setting the Power Supply Analysis Type or Power Measurement .................................. 14-1
14.2 Analyzing Switching Loss ............................................................................................... 14-2
14.3 Analyzing the Safe Operating Area ................................................................................ 14-5
14.4 Analyzing Harmonics ...................................................................................................... 14-6
14.5 Measuring the Joule Integral .......................................................................................... 14-8
14.6 Measuring Power ......................................................................................................... 14-10
Chapter 15 Displaying and Searching History Waveforms
15.1 Displaying History Waveforms ........................................................................................ 15-1
15.2 Searching History Waveforms ........................................................................................ 15-5
Chapter 16 Printing and Saving Screen Captures
16.1 Loading Roll Paper Into the Built-In Printer (Option) ...................................................... 16-1
16.2 Printing on the Built-in Printer (Option) ........................................................................... 16-3
16.3 Printing on a Network Printer (Option) ........................................................................... 16-4
16.4 Saving Screen Captures to Files .................................................................................... 16-5
16.5 Printing and Saving Screen Capture Data to Multiple Output Destinations
at the Same Time ........................................................................................................... 16-7
Chapter 17 Saving and Loading Data
17.1 Connecting USB Storage Media to the USB Port .......................................................... 17-1
17.2 Saving Waveform Data ................................................................................................... 17-2
17.3 Saving Setup Data ......................................................................................................... 17-5
17.4 Saving Other Types of Data ........................................................................................... 17-6
17.5 Loading Waveform Data ............................................................................................... 17-10
17.6 Loading Setup Data .......................................................................................................17-11
17.7 Loading Other Types of Data........................................................................................ 17-12
17.8 Performing File Operations .......................................................................................... 17-14

YOKOGAWA DLM4000 Series Specifications

General

Brand	YOKOGAWA
Model	DLM4000 Series
Category	Test Equipment
Language	English
