15-4

IM DLM4038-02EN

15.1 Displaying History Waveforms

Replay (Replay)

Press the Replay soft key to display the following menu.

Record number to start replaying

Replay speed

• Displays the oldest history waveform

• Displays the latest history waveform

• Replays waveforms toward older waveforms

• Replays waveforms toward newer waveforms

• Stops the replay

• Increases the speed by one level

• Decreases the speed by one level

Set the record number.

Set the replay speed (x1/60, x1/30, x1/10, x1/3, x1, x3, x10).
