17-16
IM DLM4038-02EN
Selecting the Type of File to List (File Filter)
Select Filter on the operation menu to display the following screen.
Select the type of file to list.
*.*: All files
*.set: Setup files
*.wdf: Waveform files
*.bmp: Image files (BMP)
*.png: Image files (PNG)
*.jpg: Image files (JPEG)
*.zwf: Waveform zone files
*.msk: Polygonal zone files
*.snp: Snapshot waveform files
*.sbl: Symbol definition files
*.csv: CSV files
Changing the Storage Medium (Change Drive)
Select Change Drive on the operation menu to display the following screen.
Select a storage medium.
Flash_Mem: Internal memory
USB: The first USB storage medium that the DLM4000 detected
USB1: The second USB storage medium that the DLM4000 detected
Network: Network drive
Note
You can also change the storage medium by highlighting the storage medium (drive) you want to change to
in the file list and pressing SET.
17.8 Performing File Operations
To Next Page
