16-15

IM DL950-02EN

Setting the Encoding Conditions

Set the count condition to x2.

When the count condition is x1

When the count condition is x4

Set the count condition to x1.

Select the edge to count pulses on¹

(A , A , B , B )

Select the edge to count pulses on

(A , A , B , B )

Select the edge to count pulses on

(A , A , B , B )

Set the count condition to x4.

When the count condition is x2

16.1 Configuring Real Time Math
