292 ZXP Series 9 Card Printer Service Manual P1086708-001

Replacement Procedures for the Printer

Procedures: Tricolor Sensor

Replacement

Replacement is performed by reversing the removal steps

Tests and Adjustments

After replacing the tricolor sensor, you will need to perform the ZMotif Service Partner Tool tricolor

sensor calibration procedure.

Note • The ZMotif Service Partner Tool only works through a USB connection to the printer.

Step 1. Launch the ZMotif Service Partner Tool.

Step 2. From the Printer Type menu, select ZXP Series 9.
