CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
PARTS LISTS 2.2 PARTS LISTS CROSS REFERENCE 2 - 4
2
Search
Book TOC
Go Back
Laser Shield Glass PL-6.4
Main Board Asm PL-8.1
Mixing Motor Asm PL-4.1
Mixing Paddle PL-4.6
Mixing Paddle Spring PL-4.7
Mixing Stage, Complete PL-4.12
Motor w/Pulley, Needle (Z1) Drive
Asm.
PL-5.8
Motor Z2 Motor (UP/DN) Asm. PL-4.2
Nut, Vent Wash Block PL-5.10
ON/OFF Switch PL-10.10
Platen PL-2.7
Power Cord, 110 VAC PL-10.1
Power Supply PL-10
Rack Guide PL-2.4
Rack Kit (w/Labels) PL-2.2
Rack Sensor PL-2.6
Red Tubing 1/16" ID x 1/8" OD PL-7.1
Safety Cover PL-1.2
Sample Loader Cover PL-1.7
Sample Loader Front Cover PL-1.6
Description Location
Sample Loader Rear Cover PL-1.5
Sample Needle PL-5.14
Sample Tubing PL-7.8
Sample Wash Block PL-5.13
Sensor, Blood In-Line PL-6.5
Sensor, Needle Drive PL-5.2
Sensor, Safety Cover PL-2.1
Sensor, X-Axis Drive PL-3.11
Sensor, Y-Axis PL-3.2
Sensor, Z2 Home/Limit PL-4.11
Sheet of Rack Labels PL-2.3
Shield, Rubber X-Axis Solenoid
Umbrella
PL-3.3
Shim, 1.2mm PL-5.6
Silicone Tubing .062" ID PL-7.13
Spiral Wrap PL-7.12
Switch (110/220) PL-10.11
Tower Back Cover PL-1.4
Tower Cover PL-1.1,
PL-1.3
Description Location
