CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
PARTS LISTS 2.1 OVERVIEW 2 - 2
2
Search
Book TOC
Go Back
2.1 OVERVIEW
This chapter contains Parts Identification information for the CELL-DYN 3000/3500 type E, F and G
Sample Loaders. It includes:
• Alphabetical Listing of Parts and a cross-reference to the PL and item number where the part is
listed (Example: the listing for Platen is PL-2.7, which means item number 7 in Parts List 2 is
the Platen)
• Illustrated Parts Breakdown
• Common Hardware Listing
This chapter was designed to be used as follows:
1. Find the part in the drawing.
2. Note the Item Number of the part.
3. Find the Item Number of the opposite page to determine the Part Number and Description.
NOTE:[NON-CE MARK] and [CE MARK] identify changes in parts used before major
modifications were made in late 1995 and early 1996. [CE MARK] parts ARE NOT
downward compatible* (cannot be field installed on old Sample Loaders).
* Exception:See TSB 97-030.
