CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
PARTS LISTS PL - 4 Tower 1 2 - 12
2
Search
Book TOC
Go Back
PL - 4 Tower 1
--- END ---
Item E (3500) F (3000) G (3500) Description
1 8921165201 N/A N/A Dual Mixing Motor Asm
N/A 8921170901 8921170901 Single Mixing Motor Asm
2 8700101801 8700101801 8700101801 Motor, Z2 Motor (UP/DN) Asm.
3 7003010 7003010 7003010 Coupler, Z2 (UP/DN) Mixing Motor
4 9211693 9211693 N/A Z2 Lead Screw with Flange Nut
5 7001029 7001029 7001029 Z2 Motor Bearing
6 9301094 9300896 9330284 [CE MARK] Mixing Paddle
9300896 9300896 9330284 [NON-CE MARK] Mixing Paddle
7 7003064 7003064 2508466 Mixing Paddle Spring
8 9211654 99211658 9601840 [CE MARK] Contact Sensor
9601790 9601780 9601780 [NON-CE MARK] Contact Sensor
9 9360200 9360200 N/A Z2 Lead Screw with Flange Nut, Mounting
Bracket, and Z2 Motor
10 9520665 9520665 9520665 Cable, Tower Sensor
11 8370830101 8370830101 8370830101 Sensor, Z2 Home/Limit
12 8921198001 N/A N/A Mixing Stage Assembly, Complete, Includes
Items 1, 2, 6, 8, 9, 11. See TSB 97-030
