CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 17 Rack Fault or Alarm 4 (m, n, o, p, q, r) Rack Sensors, 3 of 3
1 - 69
1
Search
BookTOC
GoBack
IP - 17 Rack Fault or Alarm 4 (m, n, o, p, q, r) Rack Sensors, 3 of 3
CPU
Main Bd. CN3 Pins
[CE MARK]
both 2 & 14,
[NON-CE MARK]
both
3 & 4 =
≈
+3.0V
?
Yes
Replace Defective Sensor or Cable (PL-2.6;
See Interrelationship Matrix - Pg. 3-4)
Replace CPU Main Bd.
(PL-8.1; See Interrelationship
Matrix - Pg. 3-4)
No
3
Replace CPU Main Bd. (PL-8.1; See
Interrelationship Matrix - Pg. 3-4)
Yes
No
Voltages
OK
?
