VP - 3.5 Rack Clearance Adjustment
Purpose:
Perform this procedure to adjust Rack to Beam Block clearance, Fi
ure 3-10.
1. Perform Check procedure “VP - 3.4 Rack Clearance Check” (Pa
e 3-26).
2. Loosen (2) screws (Fi
ure 3-10) inserted throu
h bottom of Platen below Beam Block. If screws
cannot be accessed with Platen installed, remove Platen (Fi
ure 3-11).
3. See Fi
ure 3-10 and Fi
ure 3-11 for proper rack clearance.
NOTE:DO NOT loosen Rack Guide(s).
4. Adjust Beam Block and ti
hten hardware.
NOTE:If Platen is removed, DO NOT install at this time.
5. Perform Check procedure “VP - 5.1 Tube Detect Sensor (Beam Block) Check” (Pa
e 3-66).
6. Go to “VP - 3.6 X-Axis Solenoid to Guide Rod Check” (Pa
e 3-31).
Special Tools
DESCRIPTION QTY PN
Rack Guide
Ali
nment Tool
1 9420084
Feeler Gau
e Set 1 1-43627-01
