IP - 6 Sample Loader Dead, No Lights, No Sounds 2 of 4
1 - 23
1
Search
Book TOC
Go Back
IP - 6 Sample Loader Dead, No Lights, No Sounds 2 of 4
Yes
- Disconnect CN1 on CPU Main Bd.
- Perform Power Supply Check VP-1
(
[CE MARK]
Measure Voltages on
Cable, NOT Main Bd.)
All Voltages
OK
?
No
1
Replace CPU Main
Bd. (PL-8.1; See
Interrelationship
Matrix - Pg.3-4)
Replace Power
Supply (PL-10;
See
Interrelationship
Matrix - Pg.3-4)
W ith Fuse Removed,
Connect Power Cord
to Sample Loader
and AC Power Outlet
2
AC Power
Across Fuse
Connector
?
Yes
AC Power
at W all Outlet
?
Replace Power Cord (PL-10.1)
3
Yes
Inform Customer
Power Input
Panel
AC Power
SL-112
No
No
