CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 14 Alarm 4 (h) Time-out Moving Mixing Paddle, 1 of 4
1 - 52
1
Search
Book TOC
Go Back
IP - 14 Alarm 4 (h) Time-out Moving Mixing Paddle, 1 of 4
Paddles
Move
UP/DN
?
1
- Power Sample Loader OFF
- Clean/Lube Z2 Lead Screw
- Tighten Coupler Screws
- Enter Manual Mode
- Move Mixing Paddles UP/DN
using
↑
Z
↓
Keys
Yes
START
Mixing
Home Sensor at
CPU Main Bd. = +5.0V
Blocked, 0.0V
Unblocked
(See Figure)
?
Replace Mixing
Home Sensor
(PL-4.11; see
Interrelationship
Matrix - Pg. 3-4)
No
Yes
2
No
SL-122E
Mixing (Z2)
Motor
Flag
Mixing
Home
Sensor
Mixing
Paddle
Mixing
Paddle
(E - Only)
Mixing
Limit
Sensor
Mixing
Contact
Sensor
Z2
Lead
Screw
Coupler
Screw
SL-131B
TP
[NON- CE MARK]
Pin 4 Mixing Limit
Pin 2 Mixing Home
Pin 10
Mixing Limit
Pin 4
Mixing Home
CN5
[CE MARK]
To Next Page
