CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 9 Alarm 4 (c) Mixing Home And Contact Sensors, 2 of 3
1 - 30
1
Search
Book TOC
Go Back
IP - 9 Alarm 4 (c) Mixing Home And Contact Sensors, 2 of 3
SL-130B
[NON- CE MARK]
Pin 6 Mixing Contact
Pin 2 Mixing Home




TP
[CE MARK]
CN5


 
Pin 4
Mixing Home
[CE
MARK]
TP11
Mixing
Replace Home
Sensor (PL-4.11;
see Interrelationship
Matrix - Pg. 3-4)
Contact
Sensor Voltages
OK
?
Yes
No
No
Replace CPU Main
Bd. (PL-8.1; see
Interrelationship
Matrix - Pg. 3-4)
Mixing (Z2)
Home and Contact
Voltages OK (See
Table & Figure)
?
1
Yes
Blocked Unblocked
[CE MARK]
Contact 3.9V < 0.15V
[CE MARK]
Home 5V 0.0V
[NON-CE MARK]
Contact 5.0V 0.0V
[NON-CE MARK]
Home 5.0V 0.0V
2
