Abbott CELL-DYN 3000 - IP - 11 Alarm 4 (e and j) Time-out Moving X-Axis,...

28 Oct
1997 20:45
CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 11 Alarm 4 (e and j) Time-out Moving X-Axis, 8 of 8
1 - 40
1
Search
Book TOC
Go Back
IP - 11 Alarm 4 (e and j) Time-out Moving X-Axis, 8 of 8
Problem
Corrected
?
Perform Total
Call
Yes
Check X-Axis Motor Speed
-
Load 10 Full Tubes in Rack
X-Axis
Moves Loaded
Rack End to End
in 4 Sec.
?
Replace X-Axis Motor (
PL-3.7
; See
Interrelationship Matrix -
Pg. 3-4
)
No
Yes
No
WITHOUT MOVING PLATEN
-
Remove Any Obstructions:
Umbrella Jam
Beam Block Tape
-
Check for Binding in Movement
-
Tighten X-Axis Pulley Set Screws
-
Check X-Axis Belt Tension
-
Ensure Sensor Flag Passes
through Center of Sensor
C2
