3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 3 Mixing Fault, 1 of 2
1 - 15
1
Search
Book TOC
Go Back
IP - 3 Mixing Fault, 1 of 2
Passes
Inspection
?
Inspect Customer Samples and
Racks Used W hen Fault Occurred
- Labeling Condition
- Number of Labels on Tube
- Condition of Tube Caps
- Defects on Bottom of Tubes
- Rack Condition
No
Correct Condition
Perform
- Rack to Laser Shield Check (VP-3.8)
- X-Axis Solenoid to Rack Guide Check (VP-3.16)
- Mixing Head Position Check (VP-6.1)
- If
[NON-CE MARK]
or European
[CE MARK] loader
perform Mixing Paddle Overcurrent Alarm Check (VP-7.1)
START
Yes
1
