Abbott CELL-DYN 3000 - IP - 20 Alarm 4 (u) Rack Number Misread, 3 of 6

28 Oct
1997 20:45
CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 20 Alarm 4 (u) Rack Number Misread, 3 of 6
1 - 77
1
Search
Book TOC
Go Back
IP - 20 Alarm 4 (u) Rack Number Misread, 3 of 6
1A
[CE MARK]
Replace Barcode Head (
PL-5.5
)
[NON-CE MARK]
Replace Barcode Decoder Bd.
(
PL-10.14
)
(See Interrelationship Matrix -
Pg.
3-4
)
[EUROPE ONLY]
Perform
VP-15
(Check Barcode Reader program
using VBCDIAG.EXE. Reprogram if
required.)
Problem
Corrected
?
No
Yes
Yes
Problem
Corrected
?
Yes
Perform Total Call
[NON-CE
MARK ONLY]
Replace
Barcode Head
(
PL-5.5
)
(See
Interrelationship
Matrix -
Pg. 3-4
)
No
Sample
Loader in
Europe
?
No
