CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 16 Alarm 4 (l) Time-out Moving Mixing Paddle, 4 of 7
1 - 63
1
Search
Book TOC
Go Back
IP - 16 Alarm 4 (l) Time-out Moving Mixing Paddle, 4 of 7
Mixing
Contact Sensor
at Main Bd. =
[CE MARK]
≈
3.9V
[NON-
CE MARK]
5.0V Paddle
UP
≈
0.0V Paddle
DOWN (See
Figure)
?
No
3
Yes
No
Perform Total Call
Replace CPU Main Bd. (
PL-8.1
)
(See Interrelationship Matrix -
Pg. 3-4
)
Problem
Corrected
?
Perform
VP-6.4
and
VP-6.5
Yes
SL-141
[CE MARK]
TP11
Mixing Contact
[NON- CE MARK]
Pin 6 Mixing Contact


 
TP
5
7
