Abbott CELL-DYN 3000 - IP - 16 Alarm 4 (l) Time-out Moving Mixing Paddle,...

28 Oct
1997 20:45
CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 16 Alarm 4 (l) Time-out Moving Mixing Paddle, 5 of 7
1 - 64
1
Search
Book TOC
Go Back
IP - 16 Alarm 4 (l) Time-out Moving Mixing Paddle, 5 of 7
SL-142










   
 
[NO N- CE
MARK]
Take
Reading
Here
[CE MARK]
TP7
Perform VP-6.4
No
Perform Total Call
Replace Contact Sensor
(PL-4.8) (See Interrelationship
Matrix - Pg. 3-4)
Problem
Corrected
?
Yes
No
CPU
Main Bd.
[NON-CE MARK]
C36, or
[CE MARK]
TP7
≥
0.7V Paddle UP
≈
0.0V Paddle
DOWN (See
Figure)
?
Yes
Perform VP-6.4
and VP-6.5
5
7
