VP - 1A Power Supply Check [CE MARK]
Purpose:
Perform this procedure to verify operation of CE Mark Loader Power Supplies.
1. Ensure Line Fuse is Correct, see Table 3 - 3.
2. Turn Power
ON
.
3. Verify LEDs flash and Beeper sounds.
4. Verify Barcode Reader PWR LED
ON
.
5. Measure volta
g
es at CN1 and U19 on CPU Main Board (see Table 3 - 4 and Fi
g
ure 3-3).
Special Tools
DESCRIPTION QTY PN
None
Table 3 - 3
Voltage Fuse Type
120VAC 1.6A FB 250V (5x20mm)
220/240 VAC 2.0A SB 250V (5x20mm)
