CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 11.2 Barcode Adjustment
3 - 145
3
Search
Book TOC
Go Back
VP - 11.2 Barcode Adjustment
Purpose:
Perform this procedure to adjust Barcode Reader.
1. Perform Check procedure “VP - 11.1 Barcode Check” (Pa
g
e 3-141).
2. Platen checks VP-3.8,VP-3.10, VP-3.16 must be correct before proceedin
g
.
3.
Old Style Laser Shield Only -
Adjust Laser Glass:
a. Remove laser shield.
b. To adjust, bend tabs sli
g
htly away from
g
lass so they just fit behind platen wall (Fi
g
ure 3-78).
c. Push
g
lass down.
WARNING:
When the safety cover sensor is blocked, li
g
ht from the Barcode Laser will be accessi-
ble. DO NOT STARE INTO BEAM.
Special Tools
DESCRIPTION QTY PN
None
