Abbott CELL-DYN 3000 - IP - 4 Incomplete Aspiration, 1 of 2

28 Oct
1997 20:45
CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
TROUBLESHOOTING
IP - 4 Incomplete Aspiration, 1 of 2
1 - 17
1
Search
Book TOC
Go Back
IP - 4 Incomplete Aspiration, 1 of 2
Blood reaches left
side of Detector
?
- Observe sample in sample line during operation
- Ensure blood sample reaches left side of Sample
Detector sensor on Analyzer. See Figure
Note:
3500 Rev G or higher - Blood sample must reach
sensor to left of Shear Valve when Shear Valve rotates
in Closed Mode only.
START
Yes
Perform Sample
Detector Adjustment.
See CELL-DYN 3000/
3500 System
Troubleshooting Guide,
VP-36
No
SL-251
3000
Blood Visible
at Output of
Sample Detector
1
2
