VP - 2 Keyboard Test
Purpose:
Perform this procedure to verify Keyboard, Status LED, and Alarm LED operation.
1. Turn Sample Loader
OFF
.
2. Observe all LEDs while turnin
g
on power. All should flash (Fi
g
ure 3-4, Pa
g
e-3-17).
3. Remove Cover to Manual Keyboard.
4. Set
BAR (1/0) Switch
to
0
.
5. Verify PRE rotary switch (if used) is set to 0 (painted dot faces 0).
6. Put Sample Loader in Manual Mode.
a. Press and Hold
MAN
and
START
.
b. Turn Power
ON
, hold keys down until BEEPING stops.
7. Press each Keyboard key. Verify BEEPING sounds and correspondin
g
LED turns
ON
when key
is pressed.
Special Tools
DESCRIPTION QTY PN
None
