IP - 11 Alarm 4 (e and j) Time-out Moving X-Axis, 7 of 8
1 - 39
1
Search
Book TOC
Go Back
IP - 11 Alarm 4 (e and j) Time-out Moving X-Axis, 7 of 8
Problem
Corrected
?
Perform Total Call
Yes
Replace CPU Main Bd.
(PL-8.1; See
Interrelationship Matrix
- Pg. 3-4)
No
Replace Solenoid (PL-3.8;
See Interrelationship Matrix -
Pg. 3-4)
Yes
Solenoids
Operate
Correctly
?
No
C1 C2
