Commonly Used Procedures 6
Agilent Nano Indenter G200 User’s Guide 6-8
Defining a General Batch
This procedure is for defining a template for a batch, which can be used
over and over again. The template specifies the test method and inputs
used to run the test.
1 Click the Test tab to reveal the Test page, as shown in Figure 6-12.
Figure 6-12Test tab
2 Click the Batch Mode icon, shown in Figure 6-13.
Figure 6-13Batch Mode icon
This will open the Batch Configuration window.
3 Click New Batch in the Batch Configuration window as shown in
Figure 6-14 on page 6-9.
