Commonly Used Procedures 6
Agilent Nano Indenter G200 User’s Guide 6-25
Changing the Indenter
1 Select Change Indenter Tip from the Tip menu, as shown in
Figure 6-35.
Figure 6-35Change Indenter Tip command from Tip menu
The head will park and the sample tray will be moved away from the
head.
NanoSuite will open the Change Indenter Tip dialog box (Figure 6-36),
reminding you to insert the two locking pins into the indenter shaft.
Figure 6-36Change Indenter Tip dialog box
When inserting the locking pins into the indenter shaft, use extreme care
to prevent damage.
