Theory 7
Agilent Nano Indenter G200 User’s Guide 7-12
(16)
(17)
(18)
(19)
For example, using a G200 system with an XP head and the following
parameters, a plot of total compliance vs (1/P) will be similar to that
shown in
Figure 7-5 on page 7-13:
Berkovich diamond on fused silica
20 independent indentations, each to a different peak force
Each symbol on the plot represents the results of one complete
indentation.
F
max
= 500 mN
F
min
= 68 mN
Additional considerations:
High force results are the most valuable for determining frame
stiffness.
Low force results are not valuable or even detrimental.
Indents having a maximum displacement of less than 200 nm should
not be included in the calculation of frame stiffness.
1
E
r
-----
1 v
2

E
-------------------
1 v
i
2

E
i
-------------------+=
1
K
-------
2E
r
---------
1
A
-------


1
K
f
-----+=
H
P
A
---=


1
A
-------
H
P
----=


1
K
-------
H
2E
r
------------
1
P
-------


1
K
f
-----+=
