Quick Start Guide 2
Agilent Nano Indenter G200 User’s Guide 2-14
3 When the disk is warm, spread a small amount of crystalbond onto
the surface of the disk.
4 Place a microscope slide onto the surface of the sample disk and
press down on the slide with wooden contacts so that the slide seats
in the crystalbond, as shown in
Figure 2-15. Move the slide around
with the wooden contacts until there are no bubbles between the
slide and the sample disk.
Figure 2-15Seating the slide into the crystalbond
5 Use pliers to remove the sample disk from the heating element and
allow the disk to cool to room temperature.
6 Turn the heating element off.
7 Mix a small amount of five-minute epoxy.
8 Using a wooden stick, place a small amount of epoxy on the slide, as
shown in
Figure 2-16.
Figure 2-16Placing epoxy on the slide
