Agilent Technologies Nano Indenter G200 - Page 49

Quick Start Guide 2
Agilent Nano Indenter G200 User’s Guide 2-30
8 In the resulting screen, type Fused silica in the Sample Name text
box as shown in
Figure 2-37.
Figure 2-37Dialog box for Sample and Method names
9 Modify method name to match Figure 2-37:
a Click the Browse . . . button to open the Open Method dialog
box.
b Click the Advanced... button in the Open Method dialog box.
c Modify method name to read >> XP >> G-Series Basic
Hardness, Modulus, Tip Cal, Load Control.msm as shown in
Figure 2-37
10 Click the Next Step button.
11 Edit the settings to find the surface and for drift to match those
shown in
Figure 2-38 on page 2-31.
