Only one port is able to allow In-band control. When In-band control is allowed at
another port, this setting cannot be made.
When Port Setup is set to 10Gbps WAN10Gbps WAN, In-band control is not performed.
This tab is not displayed in the Cable, Pass Through, and Discovery applications.
For the Discovery application, In-band control is allowed internally and the remote
control via test interface is enabled.
For the Reflector application, selecting Allow In-band controlAllow In-band control selects the following
settings in the Swap forcibly.
Swap IP address
Swap UDP/TCP ports
Src. MACSrc. MAC
Set a MAC address of the port used for the In-band control communication.
Selecting DefaultDefault uses the MAC address assigned to the port hardware.
When the following MAC addresses are set, Network Masters are not searched in the
Discovery application.
Multicast MAC address
00-00-00-00-00-00
Src. IPSrc. IP
Set an IP address of the port used for the In-band control communication.
Selecting DHCPDHCP obtains an IP address automatically. Following setting values
are fixed.
DSCP/TOS: 0x00
TTL: 20
Do not set the same IP address as the IP address set at Ethernet in the Network screen
on Instruments tool bar.
It is not able to set 0 and 224 to 225 to first one byte value.
Network maskNetwork mask
Set a network mask for In-band control.
Set a network mask and IP address so that the network does not duplicate with one
specified in Ethernet in Network screen on Instruments tool bar.
GatewayGateway
Selecting check box allows users to set the default gateway IP address.
PasswordPassword
When the check box is selected, a password with 4 to 8 characters can be set.
VLAN LevelVLAN Level
When VLAN is set to the In-band control communication, set LevelLevel and IDID.
Following setting values are fixed.
DEI: OFF
Priority: 0
Ethertype: 0x8100 (IPv4)
MiscellaneousMiscellaneous
Allow changes to interface setup Allow changes to interface setup while a test is runningwhile a test is running
