82
This is the GBD_Color_Space setting.
When Vertices/facets (0) has been selected as the Format_Flag setting
0
ITU-R BT.709
ITU-R BT.709 (using RGB)
1
xvYCC601
xvYCC601 (IEC61966-2-4-SD) (using YCbCr)
2
xvYCC709
xvYCC709 (IEC61966-2-4-HD) (using YCbCr)
3
XYZ
XYZ
When Range (1) has been selected as the Format_Flag setting
0
Reserved
Reserved
1
xvYCC601
RGB expression of xvYCC601 coordinates
2
xvYCC709
RGB expression of xvYCC709 coordinates
(10)
Color_Space
3
Reserved
Reserved
This is the Number_Vertices setting.
* This is displayed only when Vertices/facets (0) has been selected as the
Format_Flag setting.
(11)
Number_Vertices
Colorprecision =
8 bit: 4 - 8
10 bit: 4 - 6
12 bit: 4 – 5
Packed_GBD_Vertices_
Data
This is the Packed_GBD_Vertices_Data setting.
* This is displayed only when Vertices/facets (0) has been selected as the
Format_Flag setting.
Data1
Data2
Data3
(12)
Data4
Colorprecision =
8 bit: 0 - 255
10 bit: 0 - 1023
12 bit: 0 - 4095
The Y, Cb and Cr values of the colors (Data) are
set here.
Packed_Range_Data
This is the Packed_Range_Data setting.
* This is displayed only when Range (1) has been selected as the
Format_Flag setting.
Min_Red
Max_Red
Min_Green
Max_Green
Min_Blue
(13)
Max_Blue
Colorprecision =
8 bit: -3.96875 - +3.96875
10 bit: -3.9921875 - +3.9921875
12 bit: -3.998046875 - +3.998046875
The Range Data of the
colors (Red, Green and
Blue) are set here.
