ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
81
 Gamut Metadata Packet
If the transmission images have been sent by xvYCC, their color space information (range, etc.) is stored in the
Gamut Metadata Packet, and sent.
This setting determines whether the Gamut Metadata Packet is to be sent.
0
OFF
The Gamut Metadata Packet is not sent.
(1)
OFF/ON
1
ON
The Gamut Metadata Packet is sent.
Listed below are the Gamut Metadata Packet settings.
* These settings are not related to the video and audio output settings.
This is the Next_Field setting.
(This indicates whether GBD (Gamut Boundary Description) sent in this
Gamut Metadata Packet is applicable to the next video field.)
0
Not applicable
(2)
Next-Field
1
Applicable
This is the No_Current_GBD setting.
(This indicates whether GBD sent in this Gamut Metadata Packet is valid or
invalid.)
0
Invalid
(3)
No_Current_GBD
1
Valid
This is the GBD_Profile setting.
0
P0
1
P1
2
P2
(4)
GBD_Profile
3
P3
(5)
AffectedGamutSeqNum 0 - 15
This is the Affected_Gamut_Seq_Num setting.
(This indicates the number of GBD (Gamut boundary
description) sent in this Gamut Metadata Packet.)
(6)
Current_GamutSeqNum 0 - 15
This is the Current_Gamut_Seq_Num setting.
(This indicates the number of the GBD that applies to the current
video field.)
This is the Packet_Seq setting.
(This identifies what this Gamut Metadata Packet is in the Gamut Metadata
Packet Sequence.)
0
Intermediate
Intermediate packet in sequence
1
First
First packet in sequence
2
Last
Last packet in sequence
(7)
Packet_Seq
3
Only
Only packet in sequence
This is the Format_Flag setting.
(This indicates the format of the GBD sent.)
0
Vertices/Facets
Vertices/Facets description
(8)
Format_Flag
1
Range
Range description
This is the GBD_Color_Precision setting.
(This indicates the precision (bit width) of the vertex and range data in GBD.)
0
8 bit
1
10 bit
(9)
Colorprecision
2
12 bit
