ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
117
This selects the screen splitting method for the 4K×2K screen splitting
operation which uses the frame memory on the board or boards.
QuadLink
0
MODE0
Screen split-into-4 output in the form of a square
divided into 4 equal parts
1
MODE1
Screen vertically split-into-4 output
2
MODE2
Screen horizontally split-into-2 output
3
MODE3
Screen vertically split-into-2 output
4
MODE4
No split
5
MODE0 (x4 Mode)
No screen splitting (Non Dividing Mode)
6
MODE1 (x4 Mode)
Screen splitting (1) (Normal Mode)
7
MODE2 (x4 Mode)
Screen splitting (2) (Cross Mode)
8
MODE3 (x4 Mode)
Screen splitting (3) (Dividing Normal Mode)
9
MODE4 (x4 Mode)
Screen splitting (4) (Dividing Cross Mode)
Octal Link
0
MODE0
Cross-split-into-4 + Vertically split-into-2 output
1
MODE1
Vertically split-into-4 + vertically split-into-2
output
2
MODE2
Horizontally split-into-2 + screen vertically
split-into-2 output
3
MODE3
Vertically split-into-2 + vertically split-into-2
output
4
MODE4
Vertically split-into-2 + Non-dividing(1)
(Non dividing mode)
5
MODE5
Vertically split-into-2 + Non-dividing(2)
(Normal mode)
6
MODE6
Vertically split-into-2 + Non-dividing (3)
(Cross mode)
7
MODE7
Vertically split-into-2 + dividing (1)
(Dividing Normal mode)
8
MODE8
Screen vertically split-into-2 + dividing (2)
(Dividing Cross mode)
(4)
Split (0/9)
9
MODE9
No dividing
(5)
CTL0/CTL1
This is not normally used. Keep it at the low setting.
