116
3
Octal (8bit)
By using two output boards, the data is output by
Octal Link by combining the data of board #1
output channels 1 and 2 and the data of board
#2 output channels 1 and 2. The portion by
which the bit length for pattern drawing exceeds
8 bits is discarded. (Max. 12 bits with the iTMDS
format)
The 4K×2K screen splitting operation which
uses the frame memory on the board is
performed. For details on the screen splitting
method, refer to “Split” in the next section.
3
Single (16bit)
Up to 16 bits can be output by Single Link using
the two links--Master and Slave--of one
connector. The portion by which the bit length for
pattern drawing is deficient from the bit length
which has been set here is filled with zeros.
The higher bits are output to the Master and the
lower bits to the Slave.
4
Dual (16bit)
Up to 16 bits can be output by Dual Link using
two connectors. The portion by which the bit
length for pattern drawing is deficient from the bit
length which has been set here is filled with
zeros.
The higher bits are output to output channel 1
and the lower bits to output channel 2.
5
Single (Auto)
The data is output by Single Link from output
channels 1 and 2. Single (8 bits) or Single (16
bits) is automatically selected depending on the
bit length for pattern drawing.
6
Dual (Auto)
The data is output by Single Link from output
channels 1 and 2. Single (8 bits) or Single (16
bits) is automatically selected depending on the
bit length for pattern drawing.
