<DP unit setting parameters>
This sets On or Off for each channel.
The same settings as the ones described in “4.1.1 Setting the output
interfaces to ON or OFF” can also be established.
0
OFF
No output.
(1)
Output 1ch (0/1)
Output 2ch (0/1)
1
ON
Output.
Set Embedded Audio output.
* Refer to “4.12.5 Embedded Audio” about its setting.
0
OFF
Embedded audio is not output.
(2)
Audio Output (0/1)
1
ON
Embedded audio is output.
This sets the drawing mode.
For further details, refer to “b) Concerning the drawing mode” in this section.
0
Single
Output in Single mode.
1
Dual
Output in Dual mode.
(3)
Mode (0-2)
2
Split
Output in Split mode.
Note) the function is different between
VM-1820(A) and VM-1826. Refer to “(b)
Concerning drawing mode” in this section for
details.
This selects screen split mode for 4Kx2K timing.
This item is available only for VM-1826.
0
Horizontally
Horizontally split into 2.
(4)
Split (0/1)
1
Vertically
Vertically split into 2.
This sets the color space of the video output from DisplayPort.
* When the YCbCr4:2:2 format has been selected, it is not possible to
display the gray scale which has been set. Use this parameter to
check the Main Stream Attribute parameters only.
0
RGB
The video is output using RGB signals.
1
YCbCr4:4:4
The video is output using YCbCr4:4:4 signals.
(5)
Video Format (0-2)
2
YCbCr4:2:2
The video is output using YCbCr4:2:2 signals.
This sets the bit length of the output video. A setting independent of the bit
length for pattern drawing can be selected, or the same bit length can be
selected automatically.
* The portion of the bit length for pattern drawing exceeds the bit length set
here is discarded. Any deficient portion is filled with zeros.
Refer to “4.1.5 Setting the bit length (gray scale) for pattern drawing”
* The bit length setting differs according to the video format. For further
details, refer to “c) Concerning the bit length setting” in this section.
* For further details on the bit length to be output, refer to “c) Concerning
the bit length setting” in this section.
0
Auto
6, 8, 10 or 12 bits are selected here
automatically depending on the bit length for
pattern drawing.
1
6bit
6-bit output
2
8bit
8-bit output
3
10bit
10-bit output
(6)
Width (0-4)
4
12bit
12-bit output
Note: this item can be selected in case of Video
Format = 2 (YCbCr4:2:2). Refer to “c) About bit
length” for details.
This selects the Main Stream Attribute “YCbCr Colorimetry”.
* This sets only the Main Stream Attribute. To change the color difference
coefficient setting, refer to “4.1.6 Selecting RGB or YPbPr and setting the
color difference coefficients”.
0
ITU601
This sets ITU-R BT601.
(7)
Colorimetry (0/1)
1
ITU709
This sets ITU-R BT709.
This selects the Link Rate and Number of Lane setting method. (8)
Link Set Mode (0/1)
0
Auto
Output accords with the DPCD of the sink
component.
