ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
195
c) Setting contents
Displayed information
(1) Setting display information (GUI page 1)
This page displays the DisplayPort interface settings (Link Rate, Number of Lane, Main Stream Attribute)
and the link training results.
DisplayPort Infomation (DP1)
Link Rate
Lane Count
: 2.7Gbps
: 4 lanes
----- Main Stream Attribute -----
M(at a certain time)
N
: 3054
: 32768
Total
Active Start
Active
Sync
Pol
H(dot) V(line)
Synchronous Clock
Component Format
Dynamic Range
YCbCr Colorimetry
Bit Depth per Color/Component
Asyncronous
RGB
VESA Range
ITU601
8 bits
PASS
PASS
0.4V
6.0dB
LANE0
800
144
640
96
NEGA
525
35
480
2
NEGA
Clock Recovery
Channel EQ
Voltage Swing
Pre-emphasis
①
②
③
④
⑤
⑥
PASS
PASS
0.4V
6.0dB
LANE1
PASS
PASS
0.4V
6.0dB
LANE2
PASS
PASS
0.4V
6.0dB
LANE3
Interlaced vertical total ODD
Details of the displayed information are as follows.
(1) This is the port for which the setting status is displayed.
(2) Link Rate setting value
(3) Number of lane setting value
(4) Main Stream Attribute (Only supported values are displayed.)
* The Mvid value actually varies, but the value at the time of this display setting is displayed.
(5) Link training results (clock recovery, channel equalizer) for each lane
(6) Voltage swing and pre-emphasis for each lane
(1)
(2)
(3)
(4)
(5)
(6)
