This sets the voltage swing level (differential level).
0 0.4 V Output at 0.4 V
1 0.6 V Output at 0.6 V
2 0.8 V Output at 0.8 V
(4)
Voltage Swing (0-3)
3 1.2 V Output at 1.2 V
This sets the pre-emphasis level.
0 0 dB Output at 0 dB
1 3.5 dB Output at 3.5 dB
2 6.0 dB Output at 6.0 dB
(5)
Pre-emphasis (0-3)
3 9.5 dB Output at 9.5 dB
* The Training Pattern mode settings can be made only for the Main Link output. DPCD and other settings in
accordance with each pattern and level are not made.
* When returning from Training Pattern mode to normal output, the settings return to the program settings selected
thus far.
* The valid voltage swing level setting and pre-emphasis setting combinations are as follows.
Pre-emphasis Voltage Swing
0 dB 3.5 dB 6 dB 9.5 dB
0.4 V
0.6 V
0.8 V
1.2 V
