ASTRO VG Series User Manual

206
■ AVI InfoFrame
AVI InfoFrame stands for Auxiliary Video Information InfoFrame. It contains information (color space, aspect
ratio) of video data.
Select to send or not sending of AVI InfoFrame
0
OFF
Not sending
(1)
OFF/ON
1
ON
Send
The below items are setting for AVI InfoFrame. It does not affect actual video and audio signal setting.
AVI InfoFrame Type (2)
Type
2 Display only. This item can not be changed.
Set version of AVI InfoFrame.
1
Version 1
(3)
Version
2
Version 2
Set Scan Information. This is for setting if Scan process is
necessary on video or not.
0
No Data
No Data
1
Overscanned
Composed for an overscanned display.
(4)
Scan Info
2
Underscanned
Composed for an underscanned
display.
Set of Bar Info. This is to set valid/invalid of Bar Information that is
described later.
0
Data Not Valid
Bar Data not valid
1
Vertical Valid
Vert.Bar info valid
2
Horizontal Valid
Horiz.Bar info Valid
(5)
Bar Info
3
Vert. & Horiz. Valid
Vert. And Horiz. Bar Info valid
Set Active Format Information Present. This is to set valid/invalid of
Active Format Aspect Ratio that is described later.
0
No Data
No Data
(6)
ActiveF Info
1
Valid
Active Format Information Valid
Set RGB or YCbCr(Color Space of video).
0
RGB
1
YCbCr 4:2:2
(7)
RGB or YCbCr
2
YCbCr 4:4:4
Set Active Format Aspect Ratio (ratio of video part. Except Bar part of
Letter Box etc.)
0
Same Picture
1
4:3(center)
2
16:9(center)
3
14:9(center)
4
Box 16:9(top)
5
Box 14:9(top)
6
Box > 16:9(center)
7
4:3(14:9 center)
8
16:9(14:9 center)
(8)
AvtiveF Aspect
9
16:9(4:3 center)
