ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
207
Set Picture Aspect Ratio (ratio of video part. Include Bar part of Letter
Box etc.)
0
No Data
No Data
1
4:3
4:3
(9)
Picture Aspect
2
16:9
16:9
Set Non-Uniform Picture Scaling (scaled direction of video).
0
No Known
No Known non-uniform Scaling
1
Horizontal
Picture has been scaled horizontally
2
Vertical
Picture has been scaled vertically
(10)
Scaling
3
Horiz. & Vert.
Picture has been scaled horizontally
and vertically
Set Colorimetry (which coefficient of standard is used when
converting to color difference data.)
0
No Data
No Data
1
SMPTE170M
ITU601
SMPTE170M/ITU601
2
ITU709
ITU709
(11)
Colorimetry
3
Extended Valid
Extended Colorimetry Information
Valid
Set Video Format Identification Code. (12)
Video Code
0 – 64
Refer to CEA-861-E about the timing that each Code
indicates.
(13)
Repetition 1
Set Pixel Repetition Factor.
Note) this item can not be set in DP.
(14)
Top Bar 0 - 65535
Set Line Number of “End of Top Bar”.
(The size of the top Bar of Letter BOX.)
(15)
Bottom Bar 0 - 65535
Set Line Number of “Start of Bottom Bar”.
(The size of the bottom Bar of Letter BOX.)
(16)
Left Bar 0 - 65535
Set Pixel Number of “End of Left Bar”.
(The size of the left Bar of Pillar BOX.)
(17)
Right Bar 0 - 65535
Set Pixel Number of “Start of Right Bar”.
(The size of the right Bar of Pillar BOX.)
Set RGB Quantization Range
(the Quantization Range in case the Colorimetry is RGB video.)
0
Default
1
Limited Range
(18)
RGB Quan.Range
2
Full Range
Set YCC Quantization Range (the Quantization Range in case the
Colorimetry is Color Difference video.)
0
Limited Range
(19)
YCC Quan.Range
1
Full Range
Set Extended Colorimetry.
(This item is referred when “Extended Valid” is set in “Colorimetry”.)
0
XvYCC601
1
XvYCC709
2
sYCC601
3
AdobeYCC601
(20)
Extended Colo.
4
AdobeRGB
