ASTRO VG Series User Manual

330
<List of 3D pattern setting items>
The type of pattern is selected here.
0
Color Bar V-1
1
Color Bar V-2
2
Vertical Bar
3
Checker DOT
4
Checker BLOCK
The checker pattern settings are referenced.
5
Slant Color Bar
6
Slant Gray Bar
7
Raster
8

9
Window / Circle
(1)
Type (0-7)
A
Cross Hatch (it will be referred to Cross Hatch setting).
On or Off is selected for the left (L) and right (R) pattern outputs.
At the Off setting, the color set using Back Color is output.
0
L=ON, R=ON
1
L=ON, R=OFF
(2)
L,R ON/OFF (0-2)
2
L=OFF, R=ON
On/Off setting of Left and Right patterns by field.
The setting color in the Back Color is displayed if it is set off.
Note) In case of Interlace signal, or except using Frame Packing
mode, it will switch to L, R ON/OFF mode.
0 ON Pattern is output
(3)
L, R Field ON/OFF
ON/OFF
1 OFF
Pattern is not output
(4)
Level L,R
The left (L) and right (R) pattern output levels are set here.
Setting range: 0 - 100 [%]
(5)
Off Color R,G,B
The output color when Off has been selected as the L,R ON/OFF or L, R
Field ON/OFF is set here.
Setting range: 0 - 255
The pattern output mode is specified here.
0
HDMI 3D Structure
The HDMI 3D Structure setting is reference, and output.
Normally, this setting is specified.
(6)
Output Mode
1
Frame Sequential
The left (L) and right (R) patterns are drawn in the VRAM using one frame
for each.
The left (L) and right (R) frames can be output alternately by setting
Repeat to H=1 and V=2 using the ACTION simple animation function.
For details, refer to section “6.15.2 Simple animation settings.”
0 Not use
Pattern is drawn by the original value or designated
color set by pattern parameter.
(7) L, R Color (0/1)
1 Use
Patterb and background is drawn by the value set by
Left/ Right color in each right and left picture.
Set display type of « LEFT » and « RIGHT » character.
0 OFF
Not displayed.
1 TOP
Display on the top.
(8)
L, R Text (0-2)
2 CENTER
Display in center.
Set black background around « LEFT » and « RIGHT » character.
0 OFF
Does not set black around « LEFT » and « RIGHT »
character.
(9)
BkBackLRText (0/1)
1 ON Set black around « LEFT » and « RIGHT » character.
