ASTRO VG Series User Manual

Chapter 3 TIMING DATA SETTINGS
33
The values for the blanking and frontp items are calculated automatically on the basis of the data
presented above.
<For progressive scanning>
Item
Calculation formula Setting range
Blanking
Blanking = Total - Disp Time display: 0.00 to 999.999 ms
Dot display: 2 to 8192 H
Frontp
Frontp = Total - Disp - Sync - Backp Time display: 0.00 to 999.999 ms
Dot display: 0 to 8192 H
<For interlaced scanning>
Item
Calculation formula Setting range
Frontp1
(Frontp2)
Frontp1 = Total2 - Disp2 - Sync2 - Backp2
(Frontp2 = Total1 - Disp1 - Sync1 - Backp1)
Time display: 0.00 to 999.999 ms
Dot display: 0.0 to 4096.0 H
Blanking1
(Blanking2)
Blanking1 = Frontp1 + Sync1 + Backp1
(Blanking2 = Frontp2 + Sync2 + Backp2)
Time display: 0.00 to 999.999 ms
Dot display: 2.0 to 4096.0 H
