User's Manual 190 Document #: LTRT-68822
Mediant 2000
3. Configure AD-based Tel-to-IP routing rules:
a. Open the Outbound IP Routing Table page (Configuration tab > VoIP menu >
GW and IP to IP submenu > Routing > Tel to IP Routing). For more information,
see Configuring Outbound IP Routing Table on page 309.
b. Configure query-result routing rules for each IP domain (private, PBX / IP PBX,
Lync / OCS clients, and mobile), using the LDAP keywords (case-sensitive) for
the prefix destination number:
♦ PRIVATE: Private number
♦ OCS: Lync / OCS client number
♦ PBX: PBX / IP PBX number
♦ MOBILE: Mobile number
♦ LDAP_ERR: LDAP query failure
c. Configure a routing rule for routing the initial Tel call to the LDAP server, using
the value "LDAP" for denoting the IP address of the LDAP server.
d. For alternative routing, enable the alternative routing mechanism and configure
corresponding SIP reasons for alternative routing. For this feature, alternative
routing starts from the table row located under the LDAP query row.
The table below shows an example for configuring AD-based Tel-to-IP routing rules in the
Outbound IP Routing Table:
AD-Based Tel-to-IP Routing Rule Configuration Examples
Index Dest. Phone Prefix Dest. IP Address
1 PRIVATE: 10.33.45.60
2 PBX: 10.33.45.65
3 OCS: 10.33.45.68
4 MOBILE: 10.33.45.100
5 LDAP_ERR 10.33.45.80
6 * LDAP
7 * 10.33.45.72
The configured routing rule example is explained below:
Rule 1: Sends call to private telephone line (at 10.33.45.60) upon successful AD
query result for the private attribute.
Rule 2: Sends call to IP PBX (at 10.33.45.65) upon successful AD query result for the
PBX attribute.
Rule 3: Sends call to Lync client (i.e., Mediation Server at 10.33.45.68) upon
successful AD query result for the Lync attribute.
Rule 4: Sends call to user's mobile phone number (to PSTN through the device's IP
address at 10.33.45.100) upon successful AD query result for the Mobile attribute.
Rule 5: Sends call to IP address of device (10.33.45.80) if AD query failure (e.g., no
response from LDAP server or attribute not found).
Rule 6: Sends query for original destination number of received call to the LDAP
server.
