User's Manual 320 Document #: LTRT-68822
Mediant 2000
Parameter Description

The source IP address is obtained from the Contact header in the
INVITE message.
 You can configure from where the source IP address is obtained,
using the SourceIPAddressInput parameter.
 The source IP address can include the following wildcards:
"x": denotes single digits. For example, 10.8.8.xx represents all
the addresses between 10.8.8.10 and 10.8.8.99.
"*": denotes any number between 0 and 255. For example,
10.8.8.* represents all addresses between 10.8.8.0 and
Source SRD ID
[SrcSRDID]
Defines the SRD from which the incoming packet is received.
Notes:
 When the incoming INVITE matches the SRD in the routing rule, if
the 'Source IP Group ID' parameter (see below) is defined and it is
associated with a different SRD, the incoming SIP call is rejected. If
the 'Source IP Group ID' parameter is not defined, the SRD's default
IP Group is used. If there is no valid source IP Group, the call is
rejected.
 Currently, this parameter can only be configured using the ini file.
Operation (Destination)
Web: Trunk Group ID
[TrunkGroupId]
For IP-to-Tel calls: Defines the Trunk Group to where the incoming SIP
call is sent.
For IP-to-IP calls: Identifies the call as an IP-to-
IP call if this parameter is
set to -1.
Web: Trunk ID
[TrunkId]
Defines the Trunk to where the incoming SIP call is sent.
Notes:
 If both 'Trunk Group ID' and 'Trunk ID' parameters are configured in
the table, the routing is done according to the 'Trunk Group ID'
parameter.
 The method for selecting the trunk's channel to which the IP call is
sent is configured by the global parameter, ChannelSelectMode.
 Currently, this field can only be configured using the ini file.
Web: IP Profile ID
[ProfileId]
Assigns an IP Profile (configured in 'Configuring IP Profiles' on page
235) to the call.
Web: Source IP Group
ID
[SrcIPGroupID]
For IP-to-Tel calls:
Defines the IP Group associated with the incoming IP
call. This is the IP Group that sent the INVITE message. This IP Group
can later be used as the 'Serving IP Group' in the Account table for
obtaining authentication user name/password for this call (see
'Configuring Account Table' on page
215).
For IP-to-IP calls: Assigns the IP Group to the incoming IP call. This IP
Group can later be used for outbound IP routing and as the 'Serving IP
Group' in the Account table for obtaining authentication user
name/password for this call (see Configuring Account Table on page
215).
24.4 IP Destinations Connectivity Feature
The device can be configured to check the integrity of the connectivity to IP destinations of
Tel-to-IP routing rules in the Outbound IP Routing table. The IP Connectivity feature can be
used for the Alternative Routing feature, whereby the device attempts to re-route calls from
